- Length
- 8.69 m
- Beam
- 2.87 m
- Draft
- 1.22 m
- Sail area
- 31.12 m²
Specifications
Dimensions & displacement6
- Length overall
- 8.69 m
- Waterline length
- 7.47 m
- Beam
- 2.87 m
- Draft
- 1.22 m
- Displacement
- 2,600 kg
- Ballast
- 760 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 31.12 m²
- Mainsail area
- 15.53 m²
- Foresail area
- 15.61 m²
- Foretriangle height (I)
- 10.16 m
- Foretriangle base (J)
- 3.07 m
- Mainsail luff (P)
- 8.99 m
- Mainsail foot (E)
- 3.45 m
- Forestay length
- 10.61 m
Engine & propulsion4
- Engine power
- 18 hp
- Engine type
- Diesel
- Engine make
- Volvo
- Engine model
- MD2020
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Fin keel, bulb, spade rudder
Tanks2
- Fuel tank
- 30 L
- Fresh water tank
- 189 L
Production & design4
- Production started
- 1995
- Hulls built
- 331
- Builder
- Beneteau
- Designer
- Groupe Finot
Performance ratios7
- Sail area / displacement
- 16.79
- Displacement / length
- 174
- Ballast / displacement
- 29.2 %
- Comfort ratio
- 17.38
- Capsize screening
- 2.11
- Hull speed
- 6.63 kn
- Load per cm of immersion
- 147.3 kg/cm
Yacht photography
Years, generations and variants
Oceanis 2811 generation
01
1995 — status pending
