- Length
- 12.15 m
- Beam
- 3.91 m
- Draft
- 1.9 m
- Sail area
- 78.4 m²
Specifications
Dimensions & displacement7
- Length overall
- 12.15 m
- Hull length
- 11.82 m
- Waterline length
- 10.35 m
- Beam
- 3.91 m
- Draft
- 1.9 m
- Displacement
- 8,260 kg
- Mast height above water
- 17.71 m
Sails & rig9
- Rig type
- Sloop, fractional rig
- Sail area
- 78.4 m²
- Mainsail area
- 33.65 m²
- Foresail area
- 29.62 m²
- Foretriangle height (I)
- 15 m
- Foretriangle base (J)
- 3.95 m
- Mainsail luff (P)
- 14.02 m
- Mainsail foot (E)
- 4.8 m
- Forestay length
- 15.51 m
Engine & propulsion3
- Engine power
- 40 hp
- Engine type
- Diesel
- Engine make
- Yanmar
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, bulb, spade rudder
- Ballast material
- Cast iron
Tanks2
- Fuel tank
- 201 L
- Fresh water tank
- 360 L
Production & design3
- Production started
- 2007
- Builder
- Beneteau
- Designer
- Berret Racoupeau /Nauta Design
Performance ratios6
- Sail area / displacement
- 19.58
- Displacement / length
- 207.57
- Comfort ratio
- 26.33
- Capsize screening
- 1.95
- Hull speed
- 7.81 kn
- Load per cm of immersion
- 278 kg/cm
Yacht photography
Years, generations and variants
Oceanis 401 generation
01
2007 — status pending
