- Length
- 13.18 m
- Beam
- 3.94 m
- Draft
- 3.05 m
- Sail area
- 78.41 m²
Specifications
Dimensions & displacement7
- Length overall
- 13.18 m
- Waterline length
- 10.16 m
- Beam
- 3.94 m
- Draft
- 3.05 m
- Minimum draft
- 1.37 m
- Displacement
- 12,034 kg
- Ballast
- 4,763 kg
Sails & rig9
- Rig type
- Cutter
- Sail area
- 78.41 m²
- Mainsail area
- 36.29 m²
- Foresail area
- 42.14 m²
- Foretriangle height (I)
- 16.46 m
- Foretriangle base (J)
- 5.12 m
- Mainsail luff (P)
- 14.17 m
- Mainsail foot (E)
- 5.12 m
- Forestay length
- 17.24 m
Engine & propulsion2
- Engine type
- Diesel
- Engine make
- Westerbeke
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Keel with centreboard
- Ballast material
- Lead
Tanks2
- Fuel tank
- 454 L
- Fresh water tank
- 606 L
Production & design4
- Production started
- 1986
- Production ended
- 1994
- Hulls built
- 25
- Designer
- Ted Hood / D. Empacher
Performance ratios6
- Sail area / displacement
- 15.24
- Displacement / length
- 319.88
- Ballast / displacement
- 39.6 %
- Comfort ratio
- 37.4
- Capsize screening
- 1.74
- Hull speed
- 7.74 kn
Yacht photography
Years, generations and variants
Bristol 43.31 generation
01
1986–1994
