- Length
- 8.08 m
- Beam
- 2.82 m
- Draft
- 1.47 m
- Sail area
- 31.77 m²
Specifications
Dimensions & displacement6
- Length overall
- 8.08 m
- Waterline length
- 7.01 m
- Beam
- 2.82 m
- Draft
- 1.47 m
- Displacement
- 2,005 kg
- Ballast
- 778 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 31.77 m²
- Mainsail area
- 15.23 m²
- Foresail area
- 16.62 m²
- Foretriangle height (I)
- 10.82 m
- Foretriangle base (J)
- 3.07 m
- Mainsail luff (P)
- 9.3 m
- Mainsail foot (E)
- 3.28 m
- Forestay length
- 11.25 m
Engine & propulsion4
- Engine power
- 7.5 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 1GMF
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, transom-hung rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 38 L
- Fresh water tank
- 57 L
Production & design2
- Production started
- 1984
- Designer
- C&C Design Group
Performance ratios6
- Sail area / displacement
- 20.37
- Displacement / length
- 162.18
- Ballast / displacement
- 38.8 %
- Comfort ratio
- 14.67
- Capsize screening
- 2.26
- Hull speed
- 6.43 kn
Yacht photography
Years, generations and variants
C&C 27 MK V1 generation
01
1984 — status pending
