- Length
- 7.62 m
- Beam
- 2.59 m
- Draft
- 1.75 m
- Sail area
- 24.9 m²
Specifications
Dimensions & displacement8
- Length overall
- 7.62 m
- Waterline length
- 6.48 m
- Beam
- 2.59 m
- Draft
- 1.75 m
- Minimum draft
- 0.51 m
- Displacement
- 1,633 kg
- Ballast
- 544 kg
- Mast height above water
- 10.13 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 24.9 m²
- Mainsail area
- 12.52 m²
- Foresail area
- 12.12 m²
- Foretriangle height (I)
- 8.84 m
- Foretriangle base (J)
- 2.74 m
- Mainsail luff (P)
- 7.47 m
- Mainsail foot (E)
- 3.35 m
- Forestay length
- 9.25 m
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Centreboard
- Ballast material
- Water ballast
Tanks2
- Fuel tank
- 23 L
- Fresh water tank
- 19 L
Production & design1
- Production started
- 1995
Performance ratios6
- Sail area / displacement
- 18.3
- Displacement / length
- 167.49
- Ballast / displacement
- 33.3 %
- Comfort ratio
- 14.37
- Capsize screening
- 2.22
- Hull speed
- 6.18 kn
Yacht photography
Years, generations and variants
Catalina 250 (Water Balllast)1 generation
01
1995 — status pending
