- Length
- 8.97 m
- Beam
- 3.15 m
- Draft
- 1.58 m
- Sail area
- 33.82 m²
Specifications
Dimensions & displacement6
- Length overall
- 8.97 m
- Waterline length
- 7.26 m
- Beam
- 3.15 m
- Draft
- 1.58 m
- Displacement
- 3,765 kg
- Ballast
- 1,451 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 33.82 m²
- Mainsail area
- 15.48 m²
- Foresail area
- 18.36 m²
- Foretriangle height (I)
- 11.13 m
- Foretriangle base (J)
- 3.3 m
- Mainsail luff (P)
- 9.45 m
- Mainsail foot (E)
- 3.28 m
- Forestay length
- 11.6 m
Engine & propulsion4
- Engine power
- 26 hp
- Engine type
- Diesel
- Engine make
- Universal
- Engine model
- 25XPBC
Layout & accommodation1
- Headroom
- 1.83 m
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, bulb, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 72 L
- Fresh water tank
- 185 L
Production & design3
- Production started
- 1995
- Production ended
- 2010
- Designer
- Gerry Douglas
Performance ratios6
- Sail area / displacement
- 14.25
- Displacement / length
- 273.82
- Ballast / displacement
- 38.6 %
- Comfort ratio
- 22.43
- Capsize screening
- 2.04
- Hull speed
- 6.54 kn
Yacht photography
Years, generations and variants
Catalina 28 MKII1 generation
01
1995–2010
