- Length
- 9.12 m
- Beam
- 3.3 m
- Draft
- 1.6 m
- Sail area
- 41.43 m²
Specifications
Dimensions & displacement7
- Length overall
- 9.12 m
- Waterline length
- 7.62 m
- Beam
- 3.3 m
- Draft
- 1.6 m
- Displacement
- 4,627 kg
- Ballast
- 1,905 kg
- Mast height above water
- 14 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 41.43 m²
- Mainsail area
- 18.7 m²
- Foresail area
- 21.9 m²
- Foretriangle height (I)
- 12.5 m
- Foretriangle base (J)
- 3.51 m
- Mainsail luff (P)
- 10.67 m
- Mainsail foot (E)
- 3.51 m
- Forestay length
- 12.98 m
Layout & accommodation1
- Headroom
- 1.91 m
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 79 L
- Fresh water tank
- 163 L
Production & design4
- Production started
- 1976
- Production ended
- 2008
- Hulls built
- 6430
- Designer
- Frank Butler
Performance ratios6
- Sail area / displacement
- 15.22
- Displacement / length
- 291.43
- Ballast / displacement
- 41.2 %
- Comfort ratio
- 24.93
- Capsize screening
- 2
- Hull speed
- 6.7 kn
Yacht photography
Years, generations and variants
Catalina 301 generation
01
1976–2008
