- Length
- 9.45 m
- Beam
- 3.51 m
- Draft
- 1.75 m
- Sail area
- 45.8 m²
Specifications
Dimensions & displacement7
- Length overall
- 9.45 m
- Waterline length
- 8.08 m
- Beam
- 3.51 m
- Draft
- 1.75 m
- Displacement
- 4,672 kg
- Ballast
- 1,814 kg
- Mast height above water
- 14.25 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 45.8 m²
- Mainsail area
- 22.49 m²
- Foresail area
- 23.33 m²
- Foretriangle height (I)
- 13.03 m
- Foretriangle base (J)
- 3.58 m
- Mainsail luff (P)
- 11.35 m
- Mainsail foot (E)
- 3.96 m
- Forestay length
- 13.51 m
Engine & propulsion4
- Engine power
- 26 hp
- Engine type
- Diesel
- Engine make
- Universal
- Engine model
- M25XP
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, bulb, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 102 L
- Fresh water tank
- 208 L
Production & design3
- Production started
- 1999
- Production ended
- 2011
- Designer
- Gerry Douglas
Performance ratios6
- Sail area / displacement
- 16.72
- Displacement / length
- 247.09
- Ballast / displacement
- 38.8 %
- Comfort ratio
- 22.1
- Capsize screening
- 2.12
- Hull speed
- 6.9 kn
Yacht photography
Years, generations and variants
Catalina 3101 generation
01
1999–2011
