- Length
- 11.07 m
- Beam
- 3.63 m
- Draft
- 1.78 m
- Sail area
- 50.63 m²
Specifications
Dimensions & displacement7
- Length overall
- 11.07 m
- Waterline length
- 9.22 m
- Beam
- 3.63 m
- Draft
- 1.78 m
- Displacement
- 6,123 kg
- Ballast
- 2,722 kg
- Mast height above water
- 15.29 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 50.63 m²
- Mainsail area
- 21.74 m²
- Foresail area
- 29.79 m²
- Foretriangle height (I)
- 13.64 m
- Foretriangle base (J)
- 4.37 m
- Mainsail luff (P)
- 11.89 m
- Mainsail foot (E)
- 3.66 m
- Forestay length
- 14.32 m
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 95 L
- Fresh water tank
- 273 L
Production & design3
- Production started
- 1982
- Hulls built
- 1766
- Designer
- Frank Butler
Performance ratios6
- Sail area / displacement
- 15.44
- Displacement / length
- 217.73
- Ballast / displacement
- 44.4 %
- Comfort ratio
- 23.98
- Capsize screening
- 2.01
- Hull speed
- 7.37 kn
Yacht photography
Years, generations and variants
Catalina 361 generation
01
1982 — status pending
