- Length
- 11.71 m
- Beam
- 3.76 m
- Draft
- 2.19 m
- Sail area
- 67.17 m²
Specifications
Dimensions & displacement6
- Length overall
- 11.71 m
- Waterline length
- 9.88 m
- Beam
- 3.76 m
- Draft
- 2.19 m
- Displacement
- 8,618 kg
- Ballast
- 3,084 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 67.17 m²
- Mainsail area
- 32.63 m²
- Foresail area
- 34.7 m²
- Foretriangle height (I)
- 15.52 m
- Foretriangle base (J)
- 4.47 m
- Mainsail luff (P)
- 13.66 m
- Mainsail foot (E)
- 4.78 m
- Forestay length
- 16.15 m
Engine & propulsion3
- Engine power
- 42 hp
- Engine type
- Diesel
- Engine make
- Westerbeke
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
Tanks2
- Fuel tank
- 98 L
- Fresh water tank
- 386 L
Production & design2
- Production started
- 1997
- Designer
- G. Douglas / Catalina
Performance ratios6
- Sail area / displacement
- 16.31
- Displacement / length
- 248.92
- Ballast / displacement
- 35.8 %
- Comfort ratio
- 30.24
- Capsize screening
- 1.85
- Hull speed
- 7.63 kn
Yacht photography
Years, generations and variants
Catalina 3801 generation
01
1997 — status pending
