- Length
- 12.34 m
- Beam
- 4.11 m
- Draft
- 2.06 m
- Sail area
- 75.07 m²
Specifications
Dimensions & displacement6
- Length overall
- 12.34 m
- Waterline length
- 10.62 m
- Beam
- 4.11 m
- Draft
- 2.06 m
- Displacement
- 8,165 kg
- Ballast
- 3,266 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 75.07 m²
- Mainsail area
- 37.11 m²
- Foresail area
- 37.92 m²
- Foretriangle height (I)
- 16.05 m
- Foretriangle base (J)
- 4.72 m
- Mainsail luff (P)
- 14.33 m
- Mainsail foot (E)
- 5.18 m
- Forestay length
- 16.73 m
Engine & propulsion2
- Engine power
- 42 hp
- Engine type
- Diesel
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Fin keel, bulb, spade rudder
Production & design2
- Production started
- 1994
- Designer
- Frank Douglas/Gerry Douglas
Performance ratios6
- Sail area / displacement
- 18.89
- Displacement / length
- 190.18
- Ballast / displacement
- 40 %
- Comfort ratio
- 23.79
- Capsize screening
- 2.06
- Hull speed
- 7.91 kn
Yacht photography
Years, generations and variants
Catalina 4001 generation
01
1994 — status pending
