- Length
- 12.76 m
- Beam
- 4.22 m
- Draft
- 1.83 m
- Sail area
- 74.04 m²
Specifications
Dimensions & displacement6
- Length overall
- 12.76 m
- Waterline length
- 10.97 m
- Beam
- 4.22 m
- Draft
- 1.83 m
- Displacement
- 9,299 kg
- Ballast
- 3,765 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 74.04 m²
- Mainsail area
- 33.66 m²
- Foresail area
- 40.38 m²
- Foretriangle height (I)
- 16.15 m
- Foretriangle base (J)
- 5 m
- Mainsail luff (P)
- 14.25 m
- Mainsail foot (E)
- 4.72 m
- Forestay length
- 16.91 m
Engine & propulsion4
- Engine power
- 44 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 4JHBE
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
Tanks1
- Fuel tank
- 148 L
Production & design4
- Production started
- 1989
- Production ended
- 1995
- Hulls built
- 477
- Designer
- Nelson/Marek / Catalina
Performance ratios6
- Sail area / displacement
- 17.09
- Displacement / length
- 196.15
- Ballast / displacement
- 40.5 %
- Comfort ratio
- 25.38
- Capsize screening
- 2.03
- Hull speed
- 8.04 kn
Yacht photography
Years, generations and variants
Catalina 421 generation
01
1989–1995
