- Length
- 14.53 m
- Beam
- 4.27 m
- Draft
- 2.39 m
- Sail area
- 93.83 m²
Specifications
Dimensions & displacement7
- Length overall
- 14.53 m
- Waterline length
- 12.8 m
- Beam
- 4.27 m
- Draft
- 2.39 m
- Displacement
- 12,369 kg
- Ballast
- 4,091 kg
- Mast height above water
- 19.3 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 93.83 m²
- Mainsail area
- 47.85 m²
- Foresail area
- 46 m²
- Foretriangle height (I)
- 17.75 m
- Foretriangle base (J)
- 5.18 m
- Mainsail luff (P)
- 15.7 m
- Mainsail foot (E)
- 6.1 m
- Forestay length
- 18.5 m
Engine & propulsion4
- Engine power
- 76 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 4JHTE
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Fin keel, bulb, spade rudder
Tanks2
- Fuel tank
- 318 L
- Fresh water tank
- 810 L
Production & design2
- Production started
- 1998
- Designer
- Gerry Douglas
Performance ratios6
- Sail area / displacement
- 17.91
- Displacement / length
- 164.32
- Ballast / displacement
- 33.1 %
- Comfort ratio
- 28.7
- Capsize screening
- 1.86
- Hull speed
- 8.68 kn
Yacht photography
Years, generations and variants
Catalina 4701 generation
01
1998 — status pending
