- Length
- 15.37 m
- Beam
- 4.5 m
- Draft
- 1.7 m
- Sail area
- 102.94 m²
Specifications
Dimensions & displacement6
- Length overall
- 15.37 m
- Waterline length
- 13.49 m
- Beam
- 4.5 m
- Draft
- 1.7 m
- Displacement
- 16,329 kg
- Ballast
- 6,010 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 102.94 m²
- Mainsail area
- 46.26 m²
- Foresail area
- 56.66 m²
- Foretriangle height (I)
- 18.14 m
- Foretriangle base (J)
- 6.25 m
- Mainsail luff (P)
- 16.41 m
- Mainsail foot (E)
- 5.64 m
- Forestay length
- 19.18 m
Engine & propulsion2
- Engine power
- 75 hp
- Engine type
- Diesel
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Wing keel
Production & design1
- Production started
- 2001
Performance ratios6
- Sail area / displacement
- 16.33
- Displacement / length
- 185.49
- Ballast / displacement
- 36.8 %
- Comfort ratio
- 33.51
- Capsize screening
- 1.79
- Hull speed
- 8.91 kn
Yacht photography
Years, generations and variants
Catalina (Morgan) 501 generation
01
2001 — status pending
