- Length
- 10.24 m
- Beam
- 3.05 m
- Draft
- 1.68 m
- Sail area
- 48.87 m²
Specifications
Dimensions & displacement7
- Length overall
- 10.24 m
- Waterline length
- 8.33 m
- Beam
- 3.05 m
- Draft
- 1.68 m
- Displacement
- 5,443 kg
- Ballast
- 2,132 kg
- Mast height above water
- 14.63 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 48.87 m²
- Mainsail area
- 21.92 m²
- Foresail area
- 26.92 m²
- Foretriangle height (I)
- 12.8 m
- Foretriangle base (J)
- 4.21 m
- Mainsail luff (P)
- 11.06 m
- Mainsail foot (E)
- 3.96 m
- Forestay length
- 13.48 m
Engine & propulsion4
- Engine power
- 27 hp
- Engine type
- Petrol
- Engine make
- Palmer
- Engine model
- P-60
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
- Ballast material
- Cast iron
Tanks2
- Fuel tank
- 114 L
- Fresh water tank
- 151 L
Production & design4
- Production started
- 1970
- Production ended
- 1975
- Hulls built
- 352
- Designer
- William Tripp Jr.
Performance ratios6
- Sail area / displacement
- 16.11
- Displacement / length
- 262.43
- Ballast / displacement
- 39.2 %
- Comfort ratio
- 29.57
- Capsize screening
- 1.75
- Hull speed
- 7.01 kn
Yacht photography
Years, generations and variants
Columbia 34 MK II1 generation
01
1970–1975
