- Length
- 10.79 m
- Beam
- 3.66 m
- Draft
- 1.98 m
- Sail area
- 56.58 m²
Specifications
Dimensions & displacement7
- Length overall
- 10.79 m
- Waterline length
- 9.11 m
- Beam
- 3.66 m
- Draft
- 1.98 m
- Displacement
- 6,627 kg
- Ballast
- 2,025 kg
- Mast height above water
- 16.61 m
Sails & rig9
- Rig type
- Sloop, fractional rig, unstayed mast
- Sail area
- 56.58 m²
- Mainsail area
- 35.27 m²
- Foresail area
- 21.31 m²
- Foretriangle height (I)
- 12.16 m
- Foretriangle base (J)
- 3.51 m
- Mainsail luff (P)
- 13.78 m
- Mainsail foot (E)
- 5.12 m
- Forestay length
- 12.66 m
Engine & propulsion4
- Engine power
- 27 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 3GM30F
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 132 L
- Fresh water tank
- 265 L
Production & design2
- Production started
- 1993
- Designer
- David Pedrick
Performance ratios6
- Sail area / displacement
- 16.36
- Displacement / length
- 244.02
- Ballast / displacement
- 30.6 %
- Comfort ratio
- 26.15
- Capsize screening
- 1.97
- Hull speed
- 7.33 kn
Yacht photography
Years, generations and variants
Freedom 35 (Pedrick)1 generation
01
1993 — status pending
