- Length
- 13.72 m
- Beam
- 4.11 m
- Draft
- 1.5 m
- Sail area
- 67.91 m²
Specifications
Dimensions & displacement6
- Length overall
- 13.72 m
- Waterline length
- 10.49 m
- Beam
- 4.11 m
- Draft
- 1.5 m
- Displacement
- 10,429 kg
- Ballast
- 4,309 kg
Sails & rig9
- Rig type
- Sloop, fractional rig, unstayed mast
- Sail area
- 67.91 m²
- Mainsail area
- 43.25 m²
- Foresail area
- 24.7 m²
- Foretriangle height (I)
- 11.7 m
- Foretriangle base (J)
- 4.22 m
- Mainsail luff (P)
- 15.34 m
- Mainsail foot (E)
- 5.64 m
- Forestay length
- 12.44 m
Engine & propulsion4
- Engine power
- 66 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 4JH HTBE
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Wing keel
Production & design2
- Production started
- 1987
- Designer
- Gary Mull
Performance ratios6
- Sail area / displacement
- 14.52
- Displacement / length
- 252.15
- Ballast / displacement
- 41.3 %
- Comfort ratio
- 29.54
- Capsize screening
- 1.9
- Hull speed
- 7.86 kn
Yacht photography
Years, generations and variants
Freedom 45 CC1 generation
01
1987 — status pending
