- Length
- 12.06 m
- Beam
- 3.68 m
- Draft
- 1.45 m
- Sail area
- 63.55 m²
Specifications
Dimensions & displacement6
- Length overall
- 12.06 m
- Waterline length
- 9.88 m
- Beam
- 3.68 m
- Draft
- 1.45 m
- Displacement
- 8,618 kg
- Ballast
- 3,719 kg
Sails & rig9
- Rig type
- Cutter
- Sail area
- 63.55 m²
- Mainsail area
- 27.45 m²
- Foresail area
- 36.02 m²
- Foretriangle height (I)
- 14.33 m
- Foretriangle base (J)
- 5.03 m
- Mainsail luff (P)
- 12.42 m
- Mainsail foot (E)
- 4.42 m
- Forestay length
- 15.18 m
Engine & propulsion4
- Engine power
- 50 hp
- Engine type
- Diesel
- Engine make
- Perkins
- Engine model
- 4-108
Hull & construction3
- Hull material
- Fibreglass, balsa-cored sandwich
- Keel type
- Fin keel, skeg-hung rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 303 L
- Fresh water tank
- 568 L
Production & design4
- Production started
- 1981
- Production ended
- 1984
- Hulls built
- 57
- Designer
- Richard Lazzara
Performance ratios6
- Sail area / displacement
- 15.43
- Displacement / length
- 248.92
- Ballast / displacement
- 43.2 %
- Comfort ratio
- 30.83
- Capsize screening
- 1.81
- Hull speed
- 7.63 kn
Yacht photography
Years, generations and variants
Gulfstar 39 Sailmaster1 generation
01
1981–1984
