- Length
- 14.45 m
- Beam
- 4.22 m
- Draft
- 1.68 m
- Sail area
- 85.75 m²
Specifications
Dimensions & displacement6
- Length overall
- 14.45 m
- Waterline length
- 12.34 m
- Beam
- 4.22 m
- Draft
- 1.68 m
- Displacement
- 17,237 kg
- Ballast
- 4,763 kg
Sails & rig9
- Rig type
- Ketch, masthead rig
- Sail area
- 85.75 m²
- Mainsail area
- 29.52 m²
- Foresail area
- 44.84 m²
- Foretriangle height (I)
- 15.09 m
- Foretriangle base (J)
- 5.94 m
- Mainsail luff (P)
- 12.5 m
- Mainsail foot (E)
- 4.72 m
- Forestay length
- 16.22 m
Engine & propulsion2
- Engine type
- Diesel
- Engine make
- Perkins
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, skeg-hung rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 738 L
- Fresh water tank
- 1,136 L
Production & design4
- Production started
- 1978
- Production ended
- 1981
- Hulls built
- 79
- Designer
- Gulfstar/V. Lazzara
Performance ratios6
- Sail area / displacement
- 13.12
- Displacement / length
- 255.37
- Ballast / displacement
- 27.6 %
- Comfort ratio
- 41.73
- Capsize screening
- 1.65
- Hull speed
- 8.53 kn
Yacht photography
Years, generations and variants
Gulfstar 47 Sailmaster1 generation
01
1978–1981
