- Length
- 12.24 m
- Beam
- 3.73 m
- Draft
- 2.74 m
- Sail area
- 66.98 m²
Specifications
Dimensions & displacement7
- Length overall
- 12.24 m
- Waterline length
- 9.53 m
- Beam
- 3.73 m
- Draft
- 2.74 m
- Minimum draft
- 1.32 m
- Displacement
- 9,163 kg
- Ballast
- 2,948 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 66.98 m²
- Mainsail area
- 27.77 m²
- Foresail area
- 39.25 m²
- Foretriangle height (I)
- 15.15 m
- Foretriangle base (J)
- 5.18 m
- Mainsail luff (P)
- 13.01 m
- Mainsail foot (E)
- 4.27 m
- Forestay length
- 16.01 m
Engine & propulsion4
- Engine power
- 37 hp
- Engine type
- Diesel
- Engine make
- Westerbeke
- Engine model
- 4-108
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Keel with centreboard
- Ballast material
- Lead
Tanks2
- Fuel tank
- 227 L
- Fresh water tank
- 719 L
Production & design3
- Production started
- 1979
- Hulls built
- 40
- Designer
- Hank Hinckley
Performance ratios6
- Sail area / displacement
- 15.61
- Displacement / length
- 295.5
- Ballast / displacement
- 32.2 %
- Comfort ratio
- 32.71
- Capsize screening
- 1.8
- Hull speed
- 7.49 kn
Yacht photography
Years, generations and variants
Ocean Cruising 401 generation
01
1979 — status pending
