- Length
- 11.28 m
- Beam
- 3.89 m
- Draft
- 1.45 m
- Sail area
- 65.4 m²
Specifications
Dimensions & displacement7
- Length overall
- 11.28 m
- Waterline length
- 9.68 m
- Beam
- 3.89 m
- Draft
- 1.45 m
- Displacement
- 7,439 kg
- Ballast
- 2,676 kg
- Mast height above water
- 17.98 m
Sails & rig9
- Rig type
- Sloop, fractional rig
- Sail area
- 65.4 m²
- Mainsail area
- 35.28 m²
- Foresail area
- 30.1 m²
- Foretriangle height (I)
- 14.63 m
- Foretriangle base (J)
- 4.11 m
- Mainsail luff (P)
- 14.94 m
- Mainsail foot (E)
- 4.72 m
- Forestay length
- 15.2 m
Engine & propulsion4
- Engine power
- 34 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 3HM35F
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
Tanks2
- Fuel tank
- 132 L
- Fresh water tank
- 284 L
Production & design3
- Production started
- 1990
- Production ended
- 1997
- Designer
- Hunter Design Group
Performance ratios6
- Sail area / displacement
- 17.51
- Displacement / length
- 228.75
- Ballast / displacement
- 36 %
- Comfort ratio
- 25.63
- Capsize screening
- 2.01
- Hull speed
- 7.55 kn
Yacht photography
Years, generations and variants
Hunter 37.5 Legend1 generation
01
1990–1997
