- Length
- 10.46 m
- Beam
- 3.51 m
- Draft
- 1.22 m
- Sail area
- 49.33 m²
Specifications
Dimensions & displacement7
- Length overall
- 10.46 m
- Waterline length
- 8.46 m
- Beam
- 3.51 m
- Draft
- 1.22 m
- Displacement
- 4,990 kg
- Ballast
- 2,041 kg
- Mast height above water
- 13.26 m
Sails & rig9
- Rig type
- Cutter
- Sail area
- 49.33 m²
- Mainsail area
- 22.11 m²
- Foresail area
- 27.24 m²
- Foretriangle height (I)
- 12.12 m
- Foretriangle base (J)
- 4.5 m
- Mainsail luff (P)
- 10.36 m
- Mainsail foot (E)
- 4.27 m
- Forestay length
- 12.92 m
Engine & propulsion2
- Engine power
- 27 hp
- Engine type
- Diesel
Layout & accommodation1
- Headroom
- 1.91 m
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Long keel
Tanks2
- Fuel tank
- 95 L
- Fresh water tank
- 265 L
Production & design4
- Production started
- 1983
- Production ended
- 1989
- Hulls built
- 262
- Designer
- Bob Johnson
Performance ratios6
- Sail area / displacement
- 17.24
- Displacement / length
- 229.8
- Ballast / displacement
- 40.9 %
- Comfort ratio
- 22.11
- Capsize screening
- 2.07
- Hull speed
- 7.06 kn
Yacht photography
Years, generations and variants
Island Packet 311 generation
01
1983–1989
