- Length
- 10.57 m
- Beam
- 3.66 m
- Draft
- 1.3 m
- Sail area
- 67.35 m²
Specifications
Dimensions & displacement6
- Length overall
- 10.57 m
- Waterline length
- 8.94 m
- Beam
- 3.66 m
- Draft
- 1.3 m
- Displacement
- 7,257 kg
- Ballast
- 3,402 kg
Sails & rig9
- Rig type
- Cutter
- Sail area
- 67.35 m²
- Mainsail area
- 24.49 m²
- Foresail area
- 32.63 m²
- Foretriangle height (I)
- 13.66 m
- Foretriangle base (J)
- 4.78 m
- Mainsail luff (P)
- 11.28 m
- Mainsail foot (E)
- 4.34 m
- Forestay length
- 14.47 m
Engine & propulsion3
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 3JHE
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Long keel
Tanks2
- Fuel tank
- 189 L
- Fresh water tank
- 379 L
Production & design3
- Production started
- 1997
- Production ended
- 2004
- Designer
- Bob Johnson
Performance ratios6
- Sail area / displacement
- 18.34
- Displacement / length
- 283.1
- Ballast / displacement
- 46.9 %
- Comfort ratio
- 29.21
- Capsize screening
- 1.91
- Hull speed
- 7.26 kn
Yacht photography
Years, generations and variants
Island Packet 3501 generation
01
1997–2004
