- Length
- 12.19 m
- Beam
- 3.94 m
- Draft
- 1.42 m
- Sail area
- 84.26 m²
Specifications
Dimensions & displacement7
- Length overall
- 12.19 m
- Waterline length
- 10.36 m
- Beam
- 3.94 m
- Draft
- 1.42 m
- Displacement
- 10,342 kg
- Ballast
- 4,536 kg
- Mast height above water
- 16.36 m
Sails & rig9
- Rig type
- Cutter
- Sail area
- 84.26 m²
- Mainsail area
- 30.84 m²
- Foresail area
- 41.09 m²
- Foretriangle height (I)
- 15.19 m
- Foretriangle base (J)
- 5.41 m
- Mainsail luff (P)
- 13.05 m
- Mainsail foot (E)
- 4.72 m
- Forestay length
- 16.12 m
Engine & propulsion4
- Engine power
- 56 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 4JH3BE
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Long keel
- Ballast material
- Lead
Tanks2
- Fuel tank
- 341 L
- Fresh water tank
- 644 L
Production & design4
- Production started
- 1994
- Production ended
- 2000
- Hulls built
- 139
- Designer
- Bob Johnson
Performance ratios6
- Sail area / displacement
- 18.12
- Displacement / length
- 258.97
- Ballast / displacement
- 43.9 %
- Comfort ratio
- 32.6
- Capsize screening
- 1.83
- Hull speed
- 7.81 kn
Yacht photography
Years, generations and variants
Island Packet 401 generation
01
1994–2000
