- Length
- 6.86 m
- Beam
- 2.44 m
- Draft
- 1.16 m
- Sail area
- 20.72 m²
Specifications
Dimensions & displacement6
- Length overall
- 6.86 m
- Waterline length
- 5.79 m
- Beam
- 2.44 m
- Draft
- 1.16 m
- Displacement
- 812 kg
- Ballast
- 318 kg
Sails & rig8
- Rig type
- Sloop, fractional rig
- Sail area
- 20.72 m²
- Mainsail area
- 10.91 m²
- Foresail area
- 10.14 m²
- Foretriangle height (I)
- 7.56 m
- Foretriangle base (J)
- 2.68 m
- Mainsail luff (P)
- 7.96 m
- Mainsail foot (E)
- 2.74 m
Engine & propulsion1
- Engine type
- Outboard
Hull & construction4
- Hull material
- Fibreglass, balsa-cored sandwich, vinylester resin
- Keel type
- Fin keel, transom-hung rudder
- Ballast material
- Lead
- Rudder
- Transom-hung
Production & design2
- Production started
- 1983
- Designer
- Rodney S. Johnstone
Performance ratios6
- Sail area / displacement
- 24.26
- Displacement / length
- 117
- Ballast / displacement
- 39.1 %
- Comfort ratio
- 8.64
- Capsize screening
- 2.64
- Hull speed
- 5.84 kn
Yacht photography
Years, generations and variants
J/221 generation
01
1983 — status pending
