- Length
- 6.4 m
- Beam
- 2.08 m
- Draft
- 1.68 m
- Sail area
- 16.26 m²
Specifications
Dimensions & displacement7
- Length overall
- 6.4 m
- Waterline length
- 5.64 m
- Beam
- 2.08 m
- Draft
- 1.68 m
- Minimum draft
- 0.46 m
- Displacement
- 680 kg
- Ballast
- 181 kg
Sails & rig9
- Rig type
- Cutter
- Sail area
- 16.26 m²
- Mainsail area
- 9.89 m²
- Foresail area
- 8.58 m²
- Foretriangle height (I)
- 7.34 m
- Foretriangle base (J)
- 2.34 m
- Mainsail luff (P)
- 6.65 m
- Mainsail foot (E)
- 2.97 m
- Forestay length
- 7.7 m
Engine & propulsion2
- Engine power
- 10 hp
- Engine type
- Outboard
Layout & accommodation1
- Headroom
- 1.22 m
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Swing keel
- Ballast material
- Lead
Tanks1
- Fresh water tank
- 9 L
Production & design3
- Production started
- 1966
- Production ended
- 1979
- Designer
- Roger MacGregor
Performance ratios6
- Sail area / displacement
- 21.41
- Displacement / length
- 105.76
- Ballast / displacement
- 26.7 %
- Comfort ratio
- 9.31
- Capsize screening
- 2.39
- Hull speed
- 5.76 kn
Yacht photography
Years, generations and variants
Venture 211 generation
01
1966–1979
