- Length
- 8.97 m
- Beam
- 2.87 m
- Draft
- 1.37 m
- Sail area
- 41.53 m²
Specifications
Dimensions & displacement6
- Length overall
- 8.97 m
- Waterline length
- 7.47 m
- Beam
- 2.87 m
- Draft
- 1.37 m
- Displacement
- 5,002 kg
- Ballast
- 1,996 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 41.53 m²
- Mainsail area
- 19.6 m²
- Foresail area
- 22.34 m²
- Foretriangle height (I)
- 11.89 m
- Foretriangle base (J)
- 3.76 m
- Mainsail luff (P)
- 10.29 m
- Mainsail foot (E)
- 3.81 m
- Forestay length
- 12.47 m
Engine & propulsion4
- Engine power
- 13 hp
- Engine type
- Diesel
- Engine make
- Westerbeke
- Engine model
- W13
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Long keel, transom-hung rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 68 L
- Fresh water tank
- 140 L
Production & design3
- Production started
- 1980
- Hulls built
- 16
- Designer
- Chuck Paine
Performance ratios6
- Sail area / displacement
- 14.49
- Displacement / length
- 334.74
- Ballast / displacement
- 39.9 %
- Comfort ratio
- 33.07
- Capsize screening
- 1.7
- Hull speed
- 6.63 kn
Yacht photography
Years, generations and variants
Annie 301 generation
01
1980 — status pending
