- Length
- 10.69 m
- Beam
- 3.48 m
- Draft
- 1.58 m
- Sail area
- 55.56 m²
Specifications
Dimensions & displacement6
- Length overall
- 10.69 m
- Waterline length
- 8.13 m
- Beam
- 3.48 m
- Draft
- 1.58 m
- Displacement
- 6,350 kg
- Ballast
- 2,495 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 55.56 m²
- Mainsail area
- 22.06 m²
- Foresail area
- 33.45 m²
- Foretriangle height (I)
- 13.72 m
- Foretriangle base (J)
- 4.88 m
- Mainsail luff (P)
- 11.58 m
- Mainsail foot (E)
- 3.81 m
- Forestay length
- 14.56 m
Engine & propulsion4
- Engine power
- 35 hp
- Engine type
- Diesel
- Engine make
- Universal
- Engine model
- M24D
Hull & construction3
- Hull material
- Fibreglass, balsa-cored sandwich
- Keel type
- Fin keel, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 114 L
- Fresh water tank
- 303 L
Production & design4
- Production started
- 1978
- Production ended
- 1990
- Hulls built
- 260
- Designer
- Mark Ellis
Performance ratios6
- Sail area / displacement
- 16.53
- Displacement / length
- 329.47
- Ballast / displacement
- 39.3 %
- Comfort ratio
- 28.92
- Capsize screening
- 1.9
- Hull speed
- 6.92 kn
Yacht photography
Years, generations and variants
Niagara 351 generation
01
1978–1990
