- Length
- 4.27 m
- Beam
- 1.73 m
- Draft
- 1.17 m
- Sail area
- 11.61 m²
Specifications
Dimensions & displacement8
- Length overall
- 4.27 m
- Waterline length
- 4.01 m
- Beam
- 1.73 m
- Draft
- 1.17 m
- Minimum draft
- 0.15 m
- Displacement
- 215 kg
- Ballast
- 22 kg
- Mast height above water
- 7.03 m
Sails & rig2
- Rig type
- Sloop, fractional rig
- Sail area
- 11.61 m²
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Dinghy, centreboard
- Ballast material
- Steel
Production & design3
- Production started
- 1960
- Hulls built
- 5100
- Designer
- Uffa Fox
Performance ratios6
- Sail area / displacement
- 32.9
- Displacement / length
- 92.83
- Ballast / displacement
- 10.3 %
- Comfort ratio
- 5.42
- Capsize screening
- 2.91
- Hull speed
- 4.86 kn
Yacht photography
Years, generations and variants
Javelin 14 (Fox)1 generation
01
1960 — status pending
