- Length
- 11.53 m
- Beam
- 3.66 m
- Draft
- 1.98 m
- Sail area
- 65.87 m²
Specifications
Dimensions & displacement7
- Length overall
- 11.53 m
- Waterline length
- 9.3 m
- Beam
- 3.66 m
- Draft
- 1.98 m
- Displacement
- 7,031 kg
- Ballast
- 2,858 kg
- Mast height above water
- 17.07 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 65.87 m²
- Mainsail area
- 28.13 m²
- Foresail area
- 37.74 m²
- Foretriangle height (I)
- 15.24 m
- Foretriangle base (J)
- 4.95 m
- Mainsail luff (P)
- 13.18 m
- Mainsail foot (E)
- 4.27 m
- Forestay length
- 16.02 m
Engine & propulsion4
- Engine power
- 38 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 3JH2E
Layout & accommodation1
- Headroom
- 1.88 m
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
- Ballast material
- Lead
Production & design2
- Production started
- 1991
- Designer
- Bruce King
Performance ratios6
- Sail area / displacement
- 18.31
- Displacement / length
- 243.88
- Ballast / displacement
- 40.7 %
- Comfort ratio
- 26.77
- Capsize screening
- 1.93
- Hull speed
- 7.4 kn
Yacht photography
Years, generations and variants
Ericson 3801 generation
01
1991 — status pending
