- Length
- 8.28 m
- Beam
- 2.62 m
- Draft
- 1.3 m
- Sail area
- 32.42 m²
Specifications
Dimensions & displacement7
- Length overall
- 8.28 m
- Waterline length
- 6.4 m
- Beam
- 2.62 m
- Draft
- 1.3 m
- Displacement
- 2,948 kg
- Ballast
- 953 kg
- Mast height above water
- 11.28 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 32.42 m²
- Mainsail area
- 16.26 m²
- Foresail area
- 16.15 m²
- Foretriangle height (I)
- 9.91 m
- Foretriangle base (J)
- 3.26 m
- Mainsail luff (P)
- 8.53 m
- Mainsail foot (E)
- 3.81 m
- Forestay length
- 10.43 m
Engine & propulsion3
- Engine type
- Petrol
- Engine make
- Universal
- Engine model
- Atomic 4
Hull & construction3
- Hull material
- Fibreglass, solid laminate
- Keel type
- Fin keel, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 61 L
- Fresh water tank
- 76 L
Production & design4
- Production started
- 1967
- Production ended
- 1969
- Hulls built
- 173
- Designer
- William Shaw
Performance ratios6
- Sail area / displacement
- 16.08
- Displacement / length
- 313.33
- Ballast / displacement
- 32.3 %
- Comfort ratio
- 25.09
- Capsize screening
- 1.84
- Hull speed
- 6.14 kn
Yacht photography
Years, generations and variants
Renegade 271 generation
01
1967–1969
