- Length
- 9.22 m
- Beam
- 2.84 m
- Draft
- 2.13 m
- Sail area
- 39.39 m²
Specifications
Dimensions & displacement7
- Length overall
- 9.22 m
- Waterline length
- 7.11 m
- Beam
- 2.84 m
- Draft
- 2.13 m
- Minimum draft
- 1.07 m
- Displacement
- 4,445 kg
- Ballast
- 1,724 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 39.39 m²
- Mainsail area
- 20.16 m²
- Foresail area
- 18.95 m²
- Foretriangle height (I)
- 10.97 m
- Foretriangle base (J)
- 3.45 m
- Mainsail luff (P)
- 9.45 m
- Mainsail foot (E)
- 4.27 m
- Forestay length
- 11.5 m
Engine & propulsion4
- Engine power
- 30 hp
- Engine type
- Petrol
- Engine make
- Universal
- Engine model
- Atomic 4
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Keel with centreboard
- Ballast material
- Lead
Tanks2
- Fuel tank
- 76 L
- Fresh water tank
- 91 L
Production & design4
- Production started
- 1966
- Production ended
- 1971
- Hulls built
- 177
- Designer
- William Shaw
Performance ratios6
- Sail area / displacement
- 14.86
- Displacement / length
- 344.54
- Ballast / displacement
- 38.8 %
- Comfort ratio
- 30.44
- Capsize screening
- 1.75
- Hull speed
- 6.47 kn
Yacht photography
Years, generations and variants
Wanderer 301 generation
01
1966–1971
