- Length
- 9.32 m
- Beam
- 3.2 m
- Draft
- 1.62 m
- Sail area
- 42.83 m²
Specifications
Dimensions & displacement6
- Length overall
- 9.32 m
- Waterline length
- 7.77 m
- Beam
- 3.2 m
- Draft
- 1.62 m
- Displacement
- 4,264 kg
- Ballast
- 1,724 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 42.83 m²
- Mainsail area
- 19.16 m²
- Foresail area
- 23.63 m²
- Foretriangle height (I)
- 12.71 m
- Foretriangle base (J)
- 3.72 m
- Mainsail luff (P)
- 11.13 m
- Mainsail foot (E)
- 3.44 m
- Forestay length
- 13.24 m
Engine & propulsion3
- Engine power
- 18 hp
- Engine type
- Diesel
- Engine make
- Westerbeke
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Fin keel, skeg-hung rudder
Tanks2
- Fuel tank
- 76 L
- Fresh water tank
- 178 L
Production & design4
- Production started
- 1986
- Production ended
- 1993
- Hulls built
- 107
- Designer
- R.Hewson/Sabre
Performance ratios6
- Sail area / displacement
- 16.62
- Displacement / length
- 253.08
- Ballast / displacement
- 40.4 %
- Comfort ratio
- 23.46
- Capsize screening
- 1.99
- Hull speed
- 6.77 kn
Yacht photography
Years, generations and variants
Sabre 30-31 generation
01
1986–1993
