- Length
- 11.79 m
- Beam
- 3.76 m
- Draft
- 1.98 m
- Sail area
- 64.2 m²
Specifications
Dimensions & displacement6
- Length overall
- 11.79 m
- Waterline length
- 9.58 m
- Beam
- 3.76 m
- Draft
- 1.98 m
- Displacement
- 7,666 kg
- Ballast
- 2,994 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 64.2 m²
- Mainsail area
- 30.43 m²
- Foresail area
- 33.74 m²
- Foretriangle height (I)
- 15.16 m
- Foretriangle base (J)
- 4.45 m
- Mainsail luff (P)
- 13.26 m
- Mainsail foot (E)
- 4.59 m
- Forestay length
- 15.8 m
Engine & propulsion3
- Engine power
- 33 hp
- Engine type
- Diesel
- Engine make
- Westerbeke
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, skeg-hung rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 170 L
- Fresh water tank
- 401 L
Production & design4
- Production started
- 1988
- Production ended
- 1995
- Hulls built
- 114
- Designer
- Roger Hewson
Performance ratios6
- Sail area / displacement
- 16.85
- Displacement / length
- 243.23
- Ballast / displacement
- 39.1 %
- Comfort ratio
- 27.4
- Capsize screening
- 1.93
- Hull speed
- 7.51 kn
Yacht photography
Years, generations and variants
Sabre 38 MKII1 generation
01
1988–1995
