- Length
- 10.49 m
- Beam
- 3.34 m
- Draft
- 1.91 m
- Sail area
- 49.98 m²
Specifications
Dimensions & displacement6
- Length overall
- 10.49 m
- Waterline length
- 8.79 m
- Beam
- 3.34 m
- Draft
- 1.91 m
- Displacement
- 4,990 kg
- Ballast
- 1,996 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 49.98 m²
- Mainsail area
- 21.67 m²
- Foresail area
- 28.3 m²
- Foretriangle height (I)
- 13.66 m
- Foretriangle base (J)
- 4.15 m
- Mainsail luff (P)
- 11.95 m
- Mainsail foot (E)
- 3.63 m
- Forestay length
- 14.27 m
Engine & propulsion4
- Engine power
- 27 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 3GM
Hull & construction2
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
Tanks2
- Fuel tank
- 87 L
- Fresh water tank
- 216 L
Production & design4
- Production started
- 1984
- Production ended
- 1989
- Hulls built
- 110
- Designer
- Sparkman & Stephens
Performance ratios6
- Sail area / displacement
- 17.46
- Displacement / length
- 204.93
- Ballast / displacement
- 40 %
- Comfort ratio
- 22.97
- Capsize screening
- 1.97
- Hull speed
- 7.19 kn
Yacht photography
Years, generations and variants
Tartan 34-21 generation
01
1984–1989
