- Length
- 10.49 m
- Beam
- 3.63 m
- Draft
- 1.98 m
- Sail area
- 57.6 m²
Specifications
Dimensions & displacement7
- Length overall
- 10.49 m
- Waterline length
- 9.27 m
- Beam
- 3.63 m
- Draft
- 1.98 m
- Displacement
- 4,899 kg
- Ballast
- 1,588 kg
- Mast height above water
- 16.76 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 57.6 m²
- Mainsail area
- 30.37 m²
- Foresail area
- 27.24 m²
- Foretriangle height (I)
- 14.02 m
- Foretriangle base (J)
- 3.89 m
- Mainsail luff (P)
- 13.51 m
- Mainsail foot (E)
- 4.5 m
- Forestay length
- 14.55 m
Engine & propulsion2
- Engine power
- 30 hp
- Engine type
- Diesel
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 95 L
- Fresh water tank
- 227 L
Production & design2
- Production started
- 2002
- Designer
- Tim Jackett
Performance ratios6
- Sail area / displacement
- 20.37
- Displacement / length
- 171.28
- Ballast / displacement
- 32.4 %
- Comfort ratio
- 19.46
- Capsize screening
- 2.16
- Hull speed
- 7.39 kn
Yacht photography
Years, generations and variants
Tartan 3400/3451 generation
01
2002 — status pending
