- Length
- 10.72 m
- Beam
- 3.58 m
- Draft
- 1.98 m
- Sail area
- 57.53 m²
Specifications
Dimensions & displacement7
- Length overall
- 10.72 m
- Waterline length
- 9.14 m
- Beam
- 3.58 m
- Draft
- 1.98 m
- Displacement
- 5,670 kg
- Ballast
- 1,905 kg
- Mast height above water
- 16.25 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 57.53 m²
- Mainsail area
- 27.51 m²
- Foresail area
- 30.02 m²
- Foretriangle height (I)
- 14.33 m
- Foretriangle base (J)
- 4.19 m
- Mainsail luff (P)
- 12.6 m
- Mainsail foot (E)
- 4.37 m
- Forestay length
- 14.93 m
Engine & propulsion4
- Engine power
- 27 hp
- Engine type
- Diesel
- Engine make
- Yanmar
- Engine model
- 3GM30F
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 95 L
- Fresh water tank
- 273 L
Production & design2
- Production started
- 1993
- Designer
- Tim Jackett
Performance ratios6
- Sail area / displacement
- 18.46
- Displacement / length
- 206.68
- Ballast / displacement
- 33.6 %
- Comfort ratio
- 23.01
- Capsize screening
- 2.03
- Hull speed
- 7.34 kn
Yacht photography
Years, generations and variants
Tartan 35001 generation
01
1993 — status pending
