- Length
- 11.37 m
- Beam
- 3.58 m
- Draft
- 2.36 m
- Sail area
- 58.06 m²
Specifications
Dimensions & displacement8
- Length overall
- 11.37 m
- Waterline length
- 9.78 m
- Beam
- 3.58 m
- Draft
- 2.36 m
- Minimum draft
- 1.27 m
- Displacement
- 8,074 kg
- Ballast
- 3,402 kg
- Mast height above water
- 15.7 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 58.06 m²
- Mainsail area
- 23.13 m²
- Foresail area
- 34.93 m²
- Foretriangle height (I)
- 14.33 m
- Foretriangle base (J)
- 4.88 m
- Mainsail luff (P)
- 12.65 m
- Mainsail foot (E)
- 3.66 m
- Forestay length
- 15.13 m
Engine & propulsion4
- Engine power
- 40 hp
- Engine type
- Diesel
- Engine make
- Westerbeke
- Engine model
- 4-107
Hull & construction3
- Hull material
- Fibreglass, balsa-cored sandwich
- Keel type
- Keel with centreboard, skeg-hung rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 189 L
- Fresh water tank
- 341 L
Production & design4
- Production started
- 1976
- Production ended
- 1989
- Hulls built
- 486
- Designer
- Sparkman & Stephens
Performance ratios6
- Sail area / displacement
- 14.72
- Displacement / length
- 240.7
- Ballast / displacement
- 42.1 %
- Comfort ratio
- 30.72
- Capsize screening
- 1.8
- Hull speed
- 7.59 kn
Yacht photography
Years, generations and variants
Tartan 37 (S&S)1 generation
01
1976–1989
