- Length
- 11.58 m
- Beam
- 3.79 m
- Draft
- 1.62 m
- Sail area
- 61.78 m²
Specifications
Dimensions & displacement7
- Length overall
- 11.58 m
- Waterline length
- 9.45 m
- Beam
- 3.79 m
- Draft
- 1.62 m
- Displacement
- 7,257 kg
- Ballast
- 3,175 kg
- Mast height above water
- 16.76 m
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 61.78 m²
- Mainsail area
- 28.84 m²
- Foresail area
- 32.93 m²
- Foretriangle height (I)
- 15.16 m
- Foretriangle base (J)
- 4.34 m
- Mainsail luff (P)
- 13.21 m
- Mainsail foot (E)
- 4.37 m
- Forestay length
- 15.77 m
Engine & propulsion3
- Engine power
- 50 hp
- Engine type
- Diesel
- Engine make
- Yanmar
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, bulb, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 144 L
- Fresh water tank
- 303 L
Production & design4
- Production started
- 1994
- Production ended
- 1999
- Hulls built
- 43
- Designer
- Tim Jackett
Performance ratios6
- Sail area / displacement
- 16.82
- Displacement / length
- 239.77
- Ballast / displacement
- 43.8 %
- Comfort ratio
- 26.07
- Capsize screening
- 1.98
- Hull speed
- 7.46 kn
Yacht photography
Years, generations and variants
Tartan 38001 generation
01
1994–1999
