- Length
- 14.08 m
- Beam
- 4.37 m
- Draft
- 2.71 m
- Sail area
- 94.2 m²
Specifications
Dimensions & displacement6
- Length overall
- 14.08 m
- Waterline length
- 12.07 m
- Beam
- 4.37 m
- Draft
- 2.71 m
- Displacement
- 12,701 kg
- Ballast
- 3,856 kg
Sails & rig9
- Rig type
- Sloop, masthead rig
- Sail area
- 94.2 m²
- Mainsail area
- 47.22 m²
- Foresail area
- 46.99 m²
- Foretriangle height (I)
- 18.14 m
- Foretriangle base (J)
- 5.18 m
- Mainsail luff (P)
- 16.31 m
- Mainsail foot (E)
- 5.79 m
- Forestay length
- 18.86 m
Engine & propulsion3
- Engine power
- 63 hp
- Engine type
- Diesel
- Engine make
- Westerbeke / Yanmar
Hull & construction3
- Hull material
- Fibreglass
- Keel type
- Fin keel, spade rudder
- Ballast material
- Lead
Tanks2
- Fuel tank
- 265 L
- Fresh water tank
- 568 L
Production & design3
- Production started
- 1990
- Production ended
- 2001
- Designer
- Tim Jackett
Performance ratios6
- Sail area / displacement
- 17.67
- Displacement / length
- 201.29
- Ballast / displacement
- 30.4 %
- Comfort ratio
- 30.03
- Capsize screening
- 1.89
- Hull speed
- 8.43 kn
Yacht photography
Years, generations and variants
Tartan 46001 generation
01
1990–2001
